product data | sp2101 | sp2102 | sp2601 | sp2602 | sp2801 | sp2802 |
number of material components | 1k | 2k | 1k | 2k | 1k | 2k |
reciprocating pump delivery rate with 20 double strokes [l/min] | 0.6 | - | - | |||
feeding rate [l/min] | - | 1 | - | |||
dual-piston pump delivery volume [cm3/stroke] | - | - | 260 | |||
feeding pump | reciprocating pump | screw pump | dual-piston pump | |||
material feed pressure max. [bar] | 100 | 20 | 25 | |||
dimensions (w x h x d) [mm] | 900 x 1850 x 700 | 1500 x 1850 x 700 | 900 x 1850 x 700 | 1500 x 1850 x 700 | 900 x 1850 x 700 | 1500 x 1850 x 700 |
weight (without material) [kg] | 200 | 330 | 210 | 350 | 230 | 390 |
